| Hardware |
| CPU | 8 core CPU ARM Cortex-A76 + Dual core ARM Cortex-A55 @1.8GHz |
| NPU | 6Tops |
| Memory | 8GB/12GB |
| Built-in storage | 32GB/64GB |
| Cellular Interface |
| Modem | 1 × LTE Cat4 or 1 × 5G NR SA/NSA |
| Number of Antennas | 2 (LTE version) or 4 (NR version)
|
| Connector | SMA-K |
| SIM | 2×Mini SIM (2FF)（eSIM Optional） |
| Wireless Interface |
| Standards | 802.11b/g/n/ac/ax, AP or station modes
|
| Frequency Bands | 2.4 GHz & 5GHz |
| Speed | 1350Mbps (LTE version) or 750Mbps (NR version)
|
| Security | WEP, WPA, WPA2 |
| Encryption | 64/128 AES, TKIP |
| Antennas | 3 (LTE version) or 2 (NR version)
|
| Connector | SMA-K |
| GNSS Interface |
| Number of Antennas | 1(Optional) |
| Connector | SMA-K |
| Peripheral Interface |
| Ethernet | 2 × LAN 10/100/1000Mbps + 2 × WAN/LAN 10/100/1000Mbps, Gigabit Ethernet |
| Serial | 2 × RS-232 + 3 × RS-485 serial port |
| USB | 2 × USB3.0, 2 × USB2.0 |
| TF Card | 1 |
| Can | 1 |
| I/O | 2 × Relay Switch, 2 × DI |
| Audio | Audio IN/OUT |
| Display | 1 × HDMI, maximum resolution 2K@30Hz, support audio |
| Software |
| Video code | H.265/H.264/VP9, 4K@60fpsHD video decoding |
| Image processing | BMP, JPG, PNG, GIF |
| Auto Fail-over | Between:
Cellular and WAN
Cellular and Wi-Fi (station mode)
WAN and Wi-Fi (station mode) |
| Network | Muti-DNN, APN, VPDN, QoS，5G LAN |
Docker
| Support docker container function
|
| AI algorithm | Face application, fall application, flame application, people flow application, counting application, license plate application, area intrusion, petroleum work clothes application, phone call application, safety helmet application, reflective clothing application, smoke application, water gauge application, animal application, lighting application, mask application, motion detection. |
| Firewall | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List |
| VPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN |
| Remote Management | HTTP, Telnet, SSH, SMS
SNMP V1/V2/V3, SNMP TRAP
Hongdian Wedora Cloud Platform,SDLAN |
| Serial Ports Function | Transparent, Modbus RTU, etc. |
| Power Supply and Consumption |
| Connector | 3 pin socket |
| Voltage Input | DC 9~36V, including ACC |
| Power Consumption | Idle: 333mA@12V DC, Data transceiving: 598mA@12V DC |
| Others |
| Reset Button | Yes |
| LED Indicators | 4 x indicators for SYS, WiFi, NET, PWR |
| Hardware Watchdog | Yes |
| Physical Characteristics |
| Ingress Protection | IP30 |
| Housing & Weight | Aluminum+ABS plastic, about 900g |
| Dimension | 145×144×64(mm) |
| Installations | Wall-mounting |
| Operating Temperature | -20 ~ +70 °C |
| Storage Temperature | -40 ~ +80 °C |
| Relative Humidity | 0~90%(no condensation) |
| EMC |
| ESD | EN61000-4-2, level3 |
| RS | EN 61000-4-3, level3 |
| EFT | EN 61000-4-4, level3 |
| CS | EN 61000-4-6, level3 |
